ESA series
Product Features:
It features a dual-loop external control system and GB4584-2007 certification.
It offers seamless self-monitoring, excellent vibration resistance, short response times, and high reliability.
Different mounting options are available for various hazardous devices and operate in harsh environments to protect the safety of operators and equipment.
Power Supply
AC110V ~ 220V 50/60Hz, AC380V
Capacity
<15W
Output Type
Relay Contact Output
Contact Capacity
5A, AC250V / DC30V (Resistive Load)
Relay Life
Mechanical durability and electrical life are related to the connected load and are subject to change.
Response Time
≤20ms
Ambient Temperature
-10 ~ 55°C (non-freezing)
Ambient Humidity
20°C, RH≤85%
Insulation Resistance
≥100MΩ
Safety Rating
P-Type External Controller: IP54 Q-Type Internal Controller: IP20
Safety Light Curtain Parameters
Beam Area
10 mm, 20 mm, 40 mm
Resolution
20 mm, 30 mm, 40 mm
Beam
10mm beam, spacing: 8, 12, 16...... 320
20mm beam area: 4, 6, 8...... 160
40mm beam area: 4, 6, 8...... 122
Protective height
Protective height = (N-1) * beam area, where N is the beam quantity
Wavelength
940 nautical miles
Sensing distance
0.1~0.5m, 0.1~2m, 0.1~5m, 0.1~10m, 0.1~20m, 0.1~30m (Note: Please inform us when using reflective beam)
Sensing method
Reciprocal beam type
Synchronization
Cable synchronization
Anti-optical interference
10000Lux (I >5°)
Housing material
Aluminum alloy
Housing Cross-section
35 x 50 million
Protection Class
IP65 Protection Class
Vibration Resistance
10Hz ~ 55Hz, 20 times double amplitude each in the X, Y, and Z directions.
